3bar
3bar-5bar Low Pressure Rotary screw air compressor for Glass Industry/glass factory 1. Photo & Features for our Twin Rot
Basic Info.
Type | Twin-Screw Compressor |
Voltage | 380V-10000V/50Hz-60Hz |
Control Method | Intelliegent Microcomputer Control System or PLC |
Noise | Under 68dba |
Cooling Type | Wind or Water Cooling Way |
Oil Content | Under 3ppm |
Air Flow Capacity | 9.0-13.5 M3/Min |
Power | 2.2kw - 630kw |
Exhause Pressure | 0.7-1.3 MPa |
Air Displacement | 1-5000cfm |
Product | Great Brand AC Screw Air Compressor with Best Qua |
Transport Package | Export Standard Wooden Case, or as Customer Demand |
Specification | 2000*1150*1680mm |
Trademark | GREAT |
Origin | China |
HS Code | 8414809090 |
Production Capacity | 100sets/Month |
Product Description
3bar-5bar Low Pressure Rotary screw air compressor for Glass Industry/glass factory
1. Photo & Features for our Twin Rotary screw air compressor :
2. Advantages for our Tianjin Great Air Compressor Manufaturing :
Our company advantages | 1. Over 60 years China professsinal manufacture for air compressor ,An ISO9000 company |
2.European standard,China made &factory directly supply | |
3. Superior porformance &high efficiency with reasonable price | |
4. Low power consumptions for more output | |
5. Trouble free & cost saving | |
6. Timely pre-sale and after-sale service | |
7. Easy operatation &maintenance |
3.Production introduction for 3bar-5bar Low Pressure Rotary screw air compressor for Glass Industry/glass factory :
Features:
1.One shaft type structure
2.Difference speeds,permanent magnet motor with high efficiency, remarkable energy-saving effect
3.Small volume, low noise
4.Stable operation
Advantages:
The permanent magnet motor remains high efficiency at low speeds, ensuring obvious energy-saving advantages in small air volume
-Frequency range from 0%-100%(common conversion from 60%-100%)
-Compared with the fixed speed compressor, energy saving 22%-40%
-Compared with the common inverter compressor, energy saving 5%-15%
System volume fluctuations larger, the energy-saving effect more obvious.
Products range :
Motor power:5.5kw-630 kw/7.5hp-840hp , flow capacity:0.6-111 m³/min, pressure: 7-13 bar Technical Parameters:
Model | Working pressure (Bar) | Flow Air Capacity (m3/min) | Power (Kw) | Noise (dBa) | Dimensions (mm) | Outlet pipe size | Weight (Kg) |
TKLYC-7F | 7/8/10 | 1.23/1.16/1.02 | 7.5 | 65±3 | 840*670*925 | G3/4 | 350 |
TKLYC-11F | 7/8/10 | 1.65/1.62/1.4 | 7.5 | 65±3 | 1000*820*1145 | G3/4 | 390 |
TKLYC-15F | 7/8/10 | 2.65/2.24/2.1 | 15 | 65±3 | 1300*850*1257 | G1 | 410 |
TKLYC-18F | 7/8/10 | 3.1/3.0/2.7 | 18.5 | 65±3 | 1300*850*1257 | G1 | 440 |
TKLYC-22F | 7/8/10 | 3.8/3.7/3.3 | 22 | 65±3 | 1300*850*1258 | G1 | 650 |
TKLYC-30F | 7/8/10 | 5.3/5.1/4.5 | 30 | 68±3 | 1600*1100*1430 | G1 1/2 | 800 |
TKLYC-37F | 7/8/10 | 6.7/6.5/5.7 | 37 | 68±3 | 1600*1100*1430 | G1 1/2 | 850 |
TKLYC-45F | 7/8/10 | 8.6/8.0/7.1 | 45 | 68±3 | 1600*1100*1430 | G1 1/2 | 900 |
TKLYC-55F | 7/8/10 | 10.3/10.1/9.3 | 55 | 72±3 | 1750*1150*1500 | DN50 | 1650 |
TKLYC-75F | 7/8/10 | 14.0/13.5/12.5 | 75 | 72±3 | 1750*1150*1500 | DN50 | 1800 |
TKLYC-90F | 7/8/10 | 17.2/15.9/14.0 | 90 | 72±3 | 2000*1150*1680 | DN50 | 1950 |
TKLYC-110F | 7/8/10 | 21.4/19.9/18.1 | 110 | 73±3 | 2300*1540*1900 | DN80 | 2500 |
TKLYC-132F | 7/8/10 | 24.6/23.8/22.1 | 132 | 73±3 | 2300*1540*1900 | DN80 | 2600 |
TKLYC-160F | 7/8/10 | 28.7/27.1/25.2 | 160 | 75±3 | 2900*1540*2120 | DN80 | 3600 |
TKLYC-185F | 7/8/10 | 33.5/30.5/27.0 | 185 | 76±3 | 3100*1940*2389 | DN80 | 4200 |
TKLYC-200F | 7/8/10 | 36.5/33.5/30.6 | 200 | 78±3 | 3100*1940*2389 | DN100 | 4400 |
TKLYC-250F | 7/8/10 | 45.3/43.0/38.1 | 250 | 78±3 | 3400*2050*2330 | DN100 | 4900 |
4. Certificate:
5.Applications:7. FAQ:Q1: Are you factory or trade company? A1: We are factory.Q2: Warranty terms of your machine? A2: One year warranty for the machine and technical support according to your needs.Q3: Will you provide some spare parts of the machines? A3: Yes, of course.Q4: How long will you take to arrange production? A4: 380V 50HZ we can delivery the goods within 20 days. Other voltage we will delivery within 30 days.Q5: Can you accept OEM orders? A5: Yes, with professional design team, OEM orders are highly welcome!8. Contact:
